ielecssol 12V 100Watt Poly Crystalline Solar Panel

Product Specifications

Specifications:

• Module Type – 12V 100Watt


  ---

• Peak Power Watts (Pmax) – 100 W


  ---

• Maximum Power Voltage (Vmp) -17.99 Volts


  ---

• Maximum Power Current (Imp) – 5.57 Amps


  ---

• Open-circuit Voltage (Voc) -21.84 Volts


  ---

• Short-circuit Current (Isc) – 6.11 Amps


  ---

• Module Efficiency STC  – 15.91 %


  ---

Features:

• Solar Cells – A Grade Cells


  ---

• Junction Box – IP67


  ---

• Frame – Anodized Aluminium Frame


  ---

• Positive Power tolerance Guaranteed*


  ---

• Highest Module Efficiency


  ---

• Performance – High quality Glass & Solar cell, Module gives the higher Power Output in low light and cloudy weather.


  ---

Certifications:

• IEC 61215, IEC 61730, IEC 61701,


  ---

• Approved by MNRE Lab


  ---

Shipping Details:

• Module Dimension L x W x H – 945MM x 665MM x 34MM


  ---

• Weight – 7.3KG


  ---

Warranty:

• 10 Years Product Workmanship Warranty


  ---

• 25 Years Linear Power Warranty


  ---
