Product Specifications

Specifications:

• Module Type – 24V 270Watt, Mono Perc


  ---

• Peak Power Watts (Pmax) – 270 W


  ---

• Maximum Power Voltage (Vmp) – 31.9 Volts


  ---

• Maximum Power Current (Imp) – 8.47 Amps


  ---

• Open-circuit Voltage (Voc) – 39.6 Volts


  ---

• Short-circuit Current (Isc) – 9.06 Amps


  ---

• Module Efficiency STC  – 16.62 %


  ---

Features:

• Solar Cells – A Grade Cells


  ---

• Junction Box – IP67


  ---

• Frame – Anodized Aluminium Frame


  ---

• Positive Power tolerance Guaranteed*


  ---

• Highest Module Efficiency


  ---

• Performance – High-quality Glass & Solar cell, Module gives the higher Power Output in low light and cloudy weather.


  ---

Certifications:

• Approved by MNRE Lab


  ---

Shipping Details:

• Module Dimension L x W x H – 1640MM x 990MM x 35/40MM


  ---

• Weight – 17KG


  ---

Warranty:

• 10 Years Product Workmanship Warranty


  ---

• 25 Years Linear Power Warranty


  ---
