ielecssol 12W LED All in One Solar Street Light

₹12,750.00

Product Code – FAIO00069

Warranty: 18 Months



Use Coupon PREPAID get Upto 10% or Upto Rs.1000 Off on all prepaid orders.

Product Summary:

All in One Solar Street Light is a new age and compact lighting solution integrating Solar panels, LED light, a Lithium-based battery, and a PIR motion sensor. This light incorporates proprietary ielecssol LED driver technology which combines world-class battery charging technology with high efficient microprocessor-based electronics. All in One Solar Street Light uses a PIR motion sensor to adjust the LED light brightness. If no movement is detected for more than 1 minute, the brightness is reduced to one-third. This intelligent brightness control coupled with maintenance free Lithium-based battery technology provides longer backup time and better battery life. Due to its compact size, this light can be easily mounted on a pole top by anyone. The light has automatic dusk to dawn operation and needs negligible maintenance once installed. The All in One Solar Street Light uses high-quality material and is designed as per Indian environments.

Product Specifications

Specifications:

  • Light Wattage – 12W LED
  • Solar Panel – 40 Watt Mono Perc
  • Battery – 12.8V, 18Ah Lithium Ferro phosphate Battery
  • Charge controller Type – MPPT
  • Motion Sensor – Provided
  • PIR Motion Sensor – 12 Mtr. range.
  • Autonomy – 18Hrs. Backup*
  • Dusk to Dawn Operation (light will be Auto ON-OFF)
  • Adjustable mounting bracket to change the direction of All in one light
  • Dimming Operation  –  Light will glow in the fullbright mode for the rst 4 Hrs, After 4 Hrs. Light will Dim to 33% power and motion sensor for the detection of motion. If any motion is detected in the 12M area around the, then it will glow in full mode for 2 min, After that, it will again come to 33% power.*Backup depends on the sun availability & charging of the battery. 18Hrs backup calculated on one day charging.
  • Warranty – 18 Months

Indications:

  • Battery Low indication – Red LED blink
  • Solar panel charging to Battery indicator – Green LED blink
  • Full Charge indication – Green LED continuous Glow

Certifications:

  • Approved by MNRE Lab
  • IP65 Approved



  • Recommended Pole length –  5 to 6 Mtr.
  • Recommended Pole Dia – It should be Below 76MM OD
  • Dimension L x B x H- (775 x 340 x 60)mm
  • Weight – 10kg



Download Installation Guide
