ielecssol 12V/24V, 20Amp MPPT Solar Charge Controller
Original price was: ₹4,190.00.₹3,669.00Current price is: ₹3,669.00.
Product Code – FCCU00009
Warranty: 18 Months
Use Coupon PREPAID get Upto 10% or Upto Rs.1000 Off on all prepaid orders.
Product Summary:
ielecssol 12V, 20Amp solar charge controller is a compact and low power conception PV charging system that provides maximum charging efficiency in any environmental condition. This charge controller is equipped with a number of outstanding features such as charge status indication, low voltage disconnects indication, and safety functions. It works on Maximum PowerPoint Tracking (MPPT) technology. It provides three-state charging that maintains the battery health and increases the battery life also. This also includes a built-in USB charging port for charging mobile devices.
Product Specifications
Specifications:
- Charge Controller Rating – 12V/24V, 20amp
- Technology – MPPT
- Max Solar Panel Rating -24V, 320W
- Operating voltage – 12V
- Compatible for Lithium, Lead-acid Tubular & SMF Batteries.
- Warranty – 18 Months
Indications:
- Solar panel charging to battery indicator – Green LED Blink
- Battery low indication – Red LED full continuous Glow
- Full charge indication – Green LED continuous Glow
Protections:
- Battery overcharge
- Battery deep discharge
- overload short circuit
- Solar & Battery reverse connection
- Temperature compensation
Features:
- Maximum power point tracking (MPPT)
- Peak efficiency >95%
- 3 Stage charging algorithm
- Battery status through LED indication.
- USB Mobile charging output.
